MIETHKE THOMALE GUIDE
Neurochirurgisch instrument voor gecontroleerde plaatsing van ventriculaire kathetersTHOMALE GUIDE is een neurochirurgisch instrument voor gecontroleerde plaatsing van ventriculaire katheters. Het maakt geleide punctie met een ventriculaire katheter via een frontaal pre-coronair boorgat van 3 -14 mm van het ventrikel mogelijk. Dit voorkomt onjuiste positionering van de katheter bij implantatie in zeer smalle ventrikels.
Samen met de THOMALE GUIDE APP voor iPhone en iPad dient het als een eenvoudig navigatie- en geleidingshulpmiddel. Na inladen van de CT of MRI-beelden zijn plaatsingshoek, lengte van de katheter en afstand tot de middellijn eenvoudig te bepalen.
